Progressbar Widget
The progress bar shows the state of one data point as a vertical bar.
Datatypes
| Datatype | Supported? |
|---|---|
| int | ✓ |
| uint | ✓ |
| float | ✓ |
| long | ✓ |
| ulong | ✓ |
| string | ✗ |
| char | ✗ |
| bool | ✗ |
Settings
The progress bar settings include the bar color and one of three font sizes. If the "absolute values display" is chosen, then the digits displayed before, and after the comma, the unit, and the value range can be set. The values for each of these can either be imported from WinCC OA, set manually or deactivated entirely. The unit can also be manually chosen from an overview of SI units. If the "absolute values display" is deactivated, the value is displayed as a percentage.
